| Producer | BTS Engineering |
| Pump capacity, cu.m/hour | 400 |
| Feed height, m | 39.5 |
| Power capacity, kW | 45 |
| Material | cast iron |
| Input pipe diameter | DN150 |
| Output pipe diameter | DN125 |
| Rate of turn, rpm | 2 900 |
| Protection | IP55 |
| Power supply | 3х380 V, 50 Hz |
| Explosion protection | No |
| Max.flow rate, m3/h | 400 |
| Max. head, m | 39.5 |
| Max.temperature, C | 120 |
| Nom.flow rate, m3/h | 280 |
| Nom.head, m | 35 |
| Nom.pressure, Mpa | 2 |
| Seal | Mechanical Seal, Carbon-SiC-NBR |
| Impeller material | cast iron |
| Impeller diameter, mm | 190 |
| Serial number of the pump | BSM |
| Country of Origin | China |
| PumpType | console |
| Drive Type | electric |
| Installation Type | horizontal |
| Type of configuration | with engine |
| Warranty, months | 12 |
| Application | circulation, water recycling, increasing pressure, water, heating, drying, cooling tower, ice water, the drying chamber, glaze |
