| Producer | ST Pompe |
| Pump capacity, cu.m/hour | 4.8 |
| Feed height, m | 64 |
| Power capacity, kW | 1,5 |
| Material | AISI 304 stainless steel |
| Input pipe diameter | 1 1/4" |
| Output pipe diameter | 1" |
| Rate of turn, rpm | 3 000 |
| Protection | IP55 |
| Power supply | 1х220 V, 50 Hz |
| Explosion protection | No |
| Max.flow rate, m3/h | 4.8 |
| Max. head, m | 64 |
| Max.temperature, C | 90 |
| Pressure, bar | 8 |
| Seal | Mechanical Seal, Carbon/Ceramic/NBR |
| Impeller material | AISI 304 stainless steel |
| Shaft material | AISI 303 |
| Housing material | AISI 304 stainless steel |
| Suction capacity (NPSH), m | 7 |
| Serial number of the pump | CBX |
| Country of Origin | Italy |
| PumpType | console |
| Drive Type | electric |
| Installation Type | horizontal |
| Type of configuration | with engine |
| Application | beer, wine, irrigation, milk, air conditioning, water, glaze, water, heating |
| Analogue for | Ebara 2СDX, Lowara CA, Ebara 2СD |
| Weight, kg | 21 |
| Length of transport packing, cm | 500 |
| Width of transport packing, cm | 237 |
| Height of transport packing, cm | 285 |
| Producer | ST Pompe |
| Pump capacity, cu.m/hour | 4.8 |
| Feed height, m | 64 |
| Power capacity, kW | 1,5 |
| Material | AISI 304 stainless steel |
| Input pipe diameter | 1 1/4" |
| Output pipe diameter | 1" |
| Rate of turn, rpm | 3 000 |
| Protection | IP55 |
| Power supply | 1х220 V, 50 Hz |
| Explosion protection | No |
| Max.flow rate, m3/h | 4.8 |
| Max. head, m | 64 |
| Max.temperature, C | 90 |
| Pressure, bar | 8 |
| Seal | Mechanical Seal, Carbon/Ceramic/NBR |
| Impeller material | AISI 304 stainless steel |
| Shaft material | AISI 303 |
| Housing material | AISI 304 stainless steel |
| Suction capacity (NPSH), m | 7 |
| Serial number of the pump | CBX |
| Country of Origin | Italy |
| PumpType | console |
| Drive Type | electric |
| Installation Type | horizontal |
| Type of configuration | with engine |
| Application | beer, wine, irrigation, milk, air conditioning, water, glaze, water, heating |
| Analogue for | Ebara 2СDX, Lowara CA, Ebara 2СD |
| Weight, kg | 21 |
| Length of transport packing, cm | 500 |
| Width of transport packing, cm | 237 |
| Height of transport packing, cm | 285 |
Download instructions, catalog for Stainless steel pump for cooling towers CBX/200, 1.5 kW, 4.8 m3/h, 64m, 220V/M, AISI 304 (EBARA 2CDXM 70/20)
