| Producer | ST Pompe |
| Pump capacity, m3/h | 72 |
| Feed height, m | 53 |
| Power capacity, kW | 9,3 |
| Material | AISI 304 stainless steel |
| Input pipe diameter | DN65 |
| Output pipe diameter | DN50 |
| Rate of turn, rpm | 3 000 |
| Protection | IP55 |
| Power supply | 3х380 V, 50 Hz |
| Explosion protection | No |
| Max.flow rate, m3/h | 72 |
| Max. head, m | 53 |
| Max.temperature, C | 90 |
| Pressure, bar | 10 |
| Seal | Mechanical Seal, Ceramic/Carbon/NBR |
| Impeller material | AISI 304 stainless steel |
| Shaft material | AISI 304 stainless steel |
| Housing material | AISI 304 stainless steel |
| Suction capacity (NPSH), m | 7 |
| Serial number of the pump | NX |
| Country of Origin | Italy |
| PumpType | console |
| Drive Type | electric |
| Installation Type | horizontal |
| Type of configuration | with engine |
| Application | CAS, wine, urea, ammonia mixture, Braga, mudflow solution, brew, milk, Syrovatko, liquid fertilizer, juices, the drying chamber, wort, food, caustic, heating, drying, cooling tower, ice water, glaze, water, increasing pressure, water recycling, CIP-washing, salt |
| Analogue for | Ebara 3M, Speroni CX |
| Weight, kg | 73,5 |
| Length of transport packing, cm | 70 |
| Width of transport packing, cm | 35 |
| Height of transport packing, cm | 48,8 |
| Producer | ST Pompe |
| Pump capacity, m3/h | 72 |
| Feed height, m | 53 |
| Power capacity, kW | 9,3 |
| Material | AISI 304 stainless steel |
| Input pipe diameter | DN65 |
| Output pipe diameter | DN50 |
| Rate of turn, rpm | 3 000 |
| Protection | IP55 |
| Power supply | 3х380 V, 50 Hz |
| Explosion protection | No |
| Max.flow rate, m3/h | 72 |
| Max. head, m | 53 |
| Max.temperature, C | 90 |
| Pressure, bar | 10 |
| Seal | Mechanical Seal, Ceramic/Carbon/NBR |
| Impeller material | AISI 304 stainless steel |
| Shaft material | AISI 304 stainless steel |
| Housing material | AISI 304 stainless steel |
| Suction capacity (NPSH), m | 7 |
| Serial number of the pump | NX |
| Country of Origin | Italy |
| PumpType | console |
| Drive Type | electric |
| Installation Type | horizontal |
| Type of configuration | with engine |
| Application | CAS, wine, urea, ammonia mixture, Braga, mudflow solution, brew, milk, Syrovatko, liquid fertilizer, juices, the drying chamber, wort, food, caustic, heating, drying, cooling tower, ice water, glaze, water, increasing pressure, water recycling, CIP-washing, salt |
| Analogue for | Ebara 3M, Speroni CX |
| Weight, kg | 73,5 |
| Length of transport packing, cm | 70 |
| Width of transport packing, cm | 35 |
| Height of transport packing, cm | 48,8 |
Download instructions, catalog for Stainless steel pump for water supply NX50/1250 (200), 9.3 kW, 72 m3/h, 53m, 380V/T, AISI 304 (EBARA 3M 50-200/9.2)
