| Producer | ST Pompe |
| Pump capacity, cu.m/hour | 138 |
| Feed height, m | 60.5 |
| Power capacity, kW | 22 |
| Material | AISI 304 stainless steel |
| Input pipe diameter | DN80 |
| Output pipe diameter | DN65 |
| Rate of turn, rpm | 3 000 |
| Protection | IP55 |
| Power supply | 3х380 V, 50 Hz |
| Explosion protection | No |
| Max.flow rate, m3/h | 138 |
| Max. head, m | 60.5 |
| Max.temperature, C | 90 |
| Material of flow channel | AISI 304 stainless steel |
| Dimensions, mm | 880х390х532 |
| Nom.pressure, Mpa | 1 |
| Pressure, bar | 10 |
| Seal | Mechanical Seal, Ceramic/Carbon/NBR |
| Impeller material | AISI 304 stainless steel |
| Shaft material | AISI 304 stainless steel |
| Housing material | AISI 304 stainless steel |
| Suction capacity (NPSH), m | 7 |
| Serial number of the pump | NX |
| Country of Origin | Italy |
| PumpType | console |
| Drive Type | electric |
| Installation Type | horizontal |
| Type of configuration | with engine |
| Application | CAS, wine, urea, ammonia mixture, Braga, mudflow solution, brew, milk, Syrovatko, liquid fertilizer, juices, salt, wort, food, caustic, heating, drying, cooling tower, ice water, the drying chamber, glaze, water, increasing pressure, water recycling, CIP-washing |
| Analogue for | Ebara 3M, Speroni CX |
| Weight, kg | 134 |
| Length of transport packing, cm | 880 |
| Width of transport packing, cm | 390 |
| Height of transport packing, cm | 532 |
| Producer | ST Pompe |
| Pump capacity, cu.m/hour | 138 |
| Feed height, m | 60.5 |
| Power capacity, kW | 22 |
| Material | AISI 304 stainless steel |
| Input pipe diameter | DN80 |
| Output pipe diameter | DN65 |
| Rate of turn, rpm | 3 000 |
| Protection | IP55 |
| Power supply | 3х380 V, 50 Hz |
| Explosion protection | No |
| Max.flow rate, m3/h | 138 |
| Max. head, m | 60.5 |
| Max.temperature, C | 90 |
| Material of flow channel | AISI 304 stainless steel |
| Dimensions, mm | 880х390х532 |
| Nom.pressure, Mpa | 1 |
| Pressure, bar | 10 |
| Seal | Mechanical Seal, Ceramic/Carbon/NBR |
| Impeller material | AISI 304 stainless steel |
| Shaft material | AISI 304 stainless steel |
| Housing material | AISI 304 stainless steel |
| Suction capacity (NPSH), m | 7 |
| Serial number of the pump | NX |
| Country of Origin | Italy |
| PumpType | console |
| Drive Type | electric |
| Installation Type | horizontal |
| Type of configuration | with engine |
| Application | CAS, wine, urea, ammonia mixture, Braga, mudflow solution, brew, milk, Syrovatko, liquid fertilizer, juices, salt, wort, food, caustic, heating, drying, cooling tower, ice water, the drying chamber, glaze, water, increasing pressure, water recycling, CIP-washing |
| Analogue for | Ebara 3M, Speroni CX |
| Weight, kg | 134 |
| Length of transport packing, cm | 880 |
| Width of transport packing, cm | 390 |
| Height of transport packing, cm | 532 |
Download instructions, catalog for Stainless steel cooling tower pump NX65/3000 (200), 22 kW, 138 m3/h, 60.5 m, 380V/T, AISI 304 (EBARA 3M 65-200/22)
