| Producer | BTS Engineering |
| Pump capacity, m3/h | 25 |
| Feed height, m | 32 |
| Power capacity, kW | 5,5 |
| Material | cast iron |
| Input pipe diameter | 80 |
| Output pipe diameter | 80 |
| Rate of turn, rpm | 1 450 |
| Power supply | 3х380 V, 50 Hz |
| Explosion protection | No |
| Material of flow channel | cast iron |
| Nom.flow rate, m3/h | 25 |
| Nom.head, m | 32 |
| Impeller diameter, mm | 315 |
| Suction capacity (NPSH), m | 2,8 |
| Serial number of the pump | TKW |
| Country of Origin | China |
| PumpType | console |
| Drive Type | electric |
| Installation Type | horizontal |
| Type of configuration | with engine |
| Warranty, months | 12 |
| Application | irrigation, irrigation systems, for systems of water supply, extinguishing, water, cooling tower |
| Weight, kg | 135 |
| Producer | BTS Engineering |
| Pump capacity, m3/h | 25 |
| Feed height, m | 32 |
| Power capacity, kW | 5,5 |
| Material | cast iron |
| Input pipe diameter | 80 |
| Output pipe diameter | 80 |
| Rate of turn, rpm | 1 450 |
| Power supply | 3х380 V, 50 Hz |
| Explosion protection | No |
| Material of flow channel | cast iron |
| Nom.flow rate, m3/h | 25 |
| Nom.head, m | 32 |
| Impeller diameter, mm | 315 |
| Suction capacity (NPSH), m | 2,8 |
| Serial number of the pump | TKW |
| Country of Origin | China |
| PumpType | console |
| Drive Type | electric |
| Installation Type | horizontal |
| Type of configuration | with engine |
| Warranty, months | 12 |
| Application | irrigation, irrigation systems, for systems of water supply, extinguishing, water, cooling tower |
| Weight, kg | 135 |
Download instructions, catalog for TKW 80/315-5.5/4 (25/32), 5,5 kW, 1450 нorizontal centrifugal pump
