IHG BGLH 100-125(I)A (140/17), 11kW, 2880 Stainless Steel Vertical Pump
Click image for a larger view
IHG BGLH 100-125(I)A (140/17), 11kW, 2880 Stainless Steel Vertical Pump
IHG BGLH 100-125(I)A (140/17), 11kW, 2880 Stainless Steel Vertical Pump
IHG BGLH 100-125(I)A (140/17), 11kW, 2880 Stainless Steel Vertical Pump

IHG BGLH 100-125(I)A (140/17), 11kW, 2880 Stainless Steel Vertical Pump

Code: 1023982
(0 review)
ProducerBTS Engineering
Pump capacity, cu.m/hour140
Feed height, m17
Power capacity, kW11
MaterialAISI 304 stainless steel
Input pipe diameter100
Output pipe diameter100
Rate of turn, rpm2 880
ProtectionIP55
Power supply3х380 V, 50 Hz
Explosion protectionNo
Max.temperature, C120
Material of flow channelAISI 304 stainless steel
Nom.flow rate, m3/h140
Nom.head, m17
Dimensions, mm500x280x810
SealMechanical Seal, Carbon-SiC-NBR
Serial number of the pumpBGLH
Country of OriginChina
PumpTypein-line
Drive Typeelectric
Installation Typevertical
Type of configurationwith engine
Warranty, months12
Applicationvulture washing, oils, coagulant, caustic, alkalis, acid, paints, abrasive fluids, food, bards, wort
Weight, kg168
Show all features (26)
Documentation
Ukraine: Pre-order only
Poland: Pre-order only
Germany: Pre-order only
Italy: Pre-order only
$3 539,23 (netto)
Добавить в сравнение
We deliver anywhere in the world
Industrial pumps made of stainless steel AISI 304, (housing, shaft, impeller) are designed for pumping food products: juice, milk, dairy products, beer, alcohol, saline solutions, acetic acid solutions and other products. For pumping chemically aggressive liquids, sea water, alkalis, acid solutions, CAS mineral fertilizers, caustic solutions for SIP washing. For distilleries and breweries -for pumping batch, wort, used as a pump GDFO, mash and bards. Also ideal for pumping fusel oils, alcohol liquids. Pumps of this series are used for ultrafiltration and nanofiltration, permeate and filtrate supply.
Categories: Centrifugal pump inlineChemical centrifugal pumpPump for stillage, mashWine pumpIn-line pump for water supplyEvaporator pump, evaporatorPump for distillatesLiquid Fertilizer PumpPump for UANPump for beer and beer wortFood pumpBrine PumpCIP flushing of the rectification columnPumps for aggressive liquidsCaustic pumpsLye pumpsCentrifugal pumps
ProducerBTS Engineering
Pump capacity, cu.m/hour140
Feed height, m17
Power capacity, kW11
MaterialAISI 304 stainless steel
Input pipe diameter100
Output pipe diameter100
Rate of turn, rpm2 880
ProtectionIP55
Power supply3х380 V, 50 Hz
Explosion protectionNo
Max.temperature, C120
Material of flow channelAISI 304 stainless steel
Nom.flow rate, m3/h140
Nom.head, m17
Dimensions, mm500x280x810
SealMechanical Seal, Carbon-SiC-NBR
Serial number of the pumpBGLH
Country of OriginChina
PumpTypein-line
Drive Typeelectric
Installation Typevertical
Type of configurationwith engine
Warranty, months12
Applicationvulture washing, oils, coagulant, caustic, alkalis, acid, paints, abrasive fluids, food, bards, wort
Weight, kg168
