| Producer | BTS Engineering |
| Pump capacity, cu.m/hour | 50 |
| Feed height, m | 20 |
| Power capacity, kW | 5,5 |
| Material | cast iron |
| Input pipe diameter | DN80 |
| Output pipe diameter | DN80 |
| Power supply | 3х380 V, 50 Hz |
| Explosion protection | No |
| Max.temperature, C | 120 |
| Material of flow channel | cast iron |
| Nom.flow rate, m3/h | 50 |
| Nom.head, m | 20 |
| Dimensions, mm | 400x360x660 |
| Nom.pressure, Mpa | 1,6 |
| Serial number of the pump | IRG |
| Country of Origin | China |
| PumpType | in-line |
| Drive Type | electric |
| Installation Type | vertical |
| Availability of spare parts | yes |
| Warranty, months | 12 |
| Application | the drying chamber, circulation, water recycling, increasing pressure, water, glaze, ice water, cooling tower, drying, heating |
| Analogue for | Odwerk, FRISTAM, Kenle, Johnson, Inoxpa, HYPRO, Hydro-Vacuum, Honda, Omnigena, Nocchi, Grundfos, LOWARA, Kripsol, KOLMEKS, Rovatti, PERKINS, Pentax, PentairSwimmey, Packo, GEA, Hidrostal, Svanehoj, Calpeda, AlfaLaval, Aquatechnika, Aquario, APV, DAB, Cornell, Caprari, Bronzoni, Hilge, ASTA, Foras, Flygt, Ebara, Alweller, DPPumps, Varna, Hobart, Onga, Sprut, Speroni, TEREX, SOMA, Simaco, SAER, Zenit, VARISCO, Unitech, ThuneEureka, TAJFUN, SIHI, Wilo, Greenpumps, OMAC, KSB, Allweiler, Sterling |
| Weight, kg | 99 |
| Producer | BTS Engineering |
| Pump capacity, cu.m/hour | 50 |
| Feed height, m | 20 |
| Power capacity, kW | 5,5 |
| Material | cast iron |
| Input pipe diameter | DN80 |
| Output pipe diameter | DN80 |
| Power supply | 3х380 V, 50 Hz |
| Explosion protection | No |
| Max.temperature, C | 120 |
| Material of flow channel | cast iron |
| Nom.flow rate, m3/h | 50 |
| Nom.head, m | 20 |
| Dimensions, mm | 400x360x660 |
| Nom.pressure, Mpa | 1,6 |
| Serial number of the pump | IRG |
| Country of Origin | China |
| PumpType | in-line |
| Drive Type | electric |
| Installation Type | vertical |
| Availability of spare parts | yes |
| Warranty, months | 12 |
| Application | the drying chamber, circulation, water recycling, increasing pressure, water, glaze, ice water, cooling tower, drying, heating |
| Analogue for | Odwerk, FRISTAM, Kenle, Johnson, Inoxpa, HYPRO, Hydro-Vacuum, Honda, Omnigena, Nocchi, Grundfos, LOWARA, Kripsol, KOLMEKS, Rovatti, PERKINS, Pentax, PentairSwimmey, Packo, GEA, Hidrostal, Svanehoj, Calpeda, AlfaLaval, Aquatechnika, Aquario, APV, DAB, Cornell, Caprari, Bronzoni, Hilge, ASTA, Foras, Flygt, Ebara, Alweller, DPPumps, Varna, Hobart, Onga, Sprut, Speroni, TEREX, SOMA, Simaco, SAER, Zenit, VARISCO, Unitech, ThuneEureka, TAJFUN, SIHI, Wilo, Greenpumps, OMAC, KSB, Allweiler, Sterling |
| Weight, kg | 99 |
Download instructions, catalog for IRG 80-125 Centrifugal pump
