| Producer | BTS Engineering |
| Pump capacity, cu.m/hour | 3.5 |
| Feed height, m | 63 |
| Power capacity, kW | 0,75 |
| Material | AISI 304 stainless steel |
| Input pipe diameter | DN25 |
| Output pipe diameter | DN25 |
| Rate of turn, rpm | 2 900 |
| Protection | IP55 |
| Power supply | 3х380 V, 50 Hz |
| Explosion protection | No |
| Max.flow rate, m3/h | 3.5 |
| Max. head, m | 63 |
| Max.temperature, C | 120 |
| Material of flow channel | AISI 304 stainless steel |
| Nom.flow rate, m3/h | 2 |
| Nom.head, m | 52 |
| Seal | Mechanical Seal |
| Impeller material | AISI 304 stainless steel |
| Housing material | AISI 304 stainless steel |
| Serial number of the pump | BVS |
| Country of Origin | China |
| PumpType | multi-stage |
| Drive Type | electric |
| Installation Type | vertical |
| Type of configuration | with engine |
| Warranty, months | 12 |
| Application | wash, aeroponics, greenhouses, Water Treatment, steam boiler, water treatment, membranes, irrigation, washing, jets, osmosis, hydroponics, alkalis, caustic, hot water, water, water, increasing pressure, boiler, fountain |
| Analogue for | Aquatica LVR, Varna, Calpeda MXV, Dab KVC, Lowara SV, VMtec PRIMA VMEV, EBARA EVM, EBARA EVMW, Ebara EVMS, Speroni RVM, Grundfos CR |
| Weight, kg | 26 |
| Length of transport packing, cm | 29 |
| Width of transport packing, cm | 27 |
| Height of transport packing, cm | 62 |
| Height of transport volume, cbm | 0,049 |
| Producer | BTS Engineering |
| Pump capacity, cu.m/hour | 3.5 |
| Feed height, m | 63 |
| Power capacity, kW | 0,75 |
| Material | AISI 304 stainless steel |
| Input pipe diameter | DN25 |
| Output pipe diameter | DN25 |
| Rate of turn, rpm | 2 900 |
| Protection | IP55 |
| Power supply | 3х380 V, 50 Hz |
| Explosion protection | No |
| Max.flow rate, m3/h | 3.5 |
| Max. head, m | 63 |
| Max.temperature, C | 120 |
| Material of flow channel | AISI 304 stainless steel |
| Nom.flow rate, m3/h | 2 |
| Nom.head, m | 52 |
| Seal | Mechanical Seal |
| Impeller material | AISI 304 stainless steel |
| Housing material | AISI 304 stainless steel |
| Serial number of the pump | BVS |
| Country of Origin | China |
| PumpType | multi-stage |
| Drive Type | electric |
| Installation Type | vertical |
| Type of configuration | with engine |
| Warranty, months | 12 |
| Application | wash, aeroponics, greenhouses, Water Treatment, steam boiler, water treatment, membranes, irrigation, washing, jets, osmosis, hydroponics, alkalis, caustic, hot water, water, water, increasing pressure, boiler, fountain |
| Analogue for | Aquatica LVR, Varna, Calpeda MXV, Dab KVC, Lowara SV, VMtec PRIMA VMEV, EBARA EVM, EBARA EVMW, Ebara EVMS, Speroni RVM, Grundfos CR |
| Weight, kg | 26 |
| Length of transport packing, cm | 29 |
| Width of transport packing, cm | 27 |
| Height of transport packing, cm | 62 |
| Height of transport volume, cbm | 0,049 |
Download instructions, catalog for Stainless multistage pump BVS 2-7, 0.75 kW, AISI 304
