| Producer | FLUIMAC |
| Pump capacity, cu.m/hour | 0.48 |
| Feed height, m | 80 |
| Material | PVDF |
| Input pipe diameter | 1/4" |
| Output pipe diameter | 1/4" |
| Noise level ,dB | 62 |
| Explosion protection | Yes |
| Max.flow rate, m3/h | 0.48 |
| Max. head, m | 80 |
| Max.temperature, C | 95 |
| Material of flow channel | PVDF |
| Max.viscosity, cPs | 6 000 |
| Max.air pressure, bar | 8 |
| Flow rate, l/min | 8 |
| Max.diameter of solid inclusions, mm | 2,5 |
| Model | PHOENIX ATEX 07 |
| Diametr of the product line | 1/4" |
| Diameter of the pneumatic mainline | 4 mm |
| Material of ball valves | PTFE |
| Diaphragm material at air side | NBR+PTFE |
| Diaphragm material at water side | PTFE |
| Material of valve seat | PVDF |
| Dry suction height, m | 3 |
| Suction capacity (NPSH), m | 9,8 |
| Serial number of the pump | PHOENIX ATEX |
| Country of Origin | Italy |
| PumpType | membrane pneumatic |
| Drive Type | pneumatic |
| Availability of spare parts | yes |
| Warranty, months | 12 |
| Application | varnish, ammonia, ash, paints, nitric acid, acetic acid, alkalis, viscous liquids, slip, clays, butane, oleum, saturated amine, urea, carbonate, kaolin suspension, slag, phenol, alcohol, reverse osmosis systems, sulfur, hydrogen, peroxide, ethers, ethylene, phosphoric acid, phosphates, formalin |
| Analogue for | Milwaukee, Injecta, AQUA, Jesco Pump, Seko, FWT, Debem SANIBOXER, PRODOSE, DOSITEC, Astralpool, AGRAL DDE-300, Emec, Sera, MILTON ROY, Grundfos, ProMinent, Graco Husky, WILDEN, AquaViva, AGRAL DDE-160, AGRAL DDE-600, YAMADA NDP, DUOTEK FOOD, DEPA РМ (Р), DELLMECO DMCX, DELLMECO DM, Duotek AF Zone 2 Atex, AlphaDynamic Ruby, DUOTEK SANI, AGRAL DDE-100, AGRAL DDE-60, AGRAL DDE-030, DEPA L, DEPA DB, DEPA М, Debem FOODBOXER, Debem BOXER |
| Weight, kg | 0,7 |
| Producer | FLUIMAC |
| Pump capacity, cu.m/hour | 0.48 |
| Feed height, m | 80 |
| Material | PVDF |
| Input pipe diameter | 1/4" |
| Output pipe diameter | 1/4" |
| Noise level ,dB | 62 |
| Explosion protection | Yes |
| Max.flow rate, m3/h | 0.48 |
| Max. head, m | 80 |
| Max.temperature, C | 95 |
| Material of flow channel | PVDF |
| Max.viscosity, cPs | 6 000 |
| Max.air pressure, bar | 8 |
| Flow rate, l/min | 8 |
| Max.diameter of solid inclusions, mm | 2,5 |
| Model | PHOENIX ATEX 07 |
| Diametr of the product line | 1/4" |
| Diameter of the pneumatic mainline | 4 mm |
| Material of ball valves | PTFE |
| Diaphragm material at air side | NBR+PTFE |
| Diaphragm material at water side | PTFE |
| Material of valve seat | PVDF |
| Dry suction height, m | 3 |
| Suction capacity (NPSH), m | 9,8 |
| Serial number of the pump | PHOENIX ATEX |
| Country of Origin | Italy |
| PumpType | membrane pneumatic |
| Drive Type | pneumatic |
| Availability of spare parts | yes |
| Warranty, months | 12 |
| Application | varnish, ammonia, ash, paints, nitric acid, acetic acid, alkalis, viscous liquids, slip, clays, butane, oleum, saturated amine, urea, carbonate, kaolin suspension, slag, phenol, alcohol, reverse osmosis systems, sulfur, hydrogen, peroxide, ethers, ethylene, phosphoric acid, phosphates, formalin |
| Analogue for | Milwaukee, Injecta, AQUA, Jesco Pump, Seko, FWT, Debem SANIBOXER, PRODOSE, DOSITEC, Astralpool, AGRAL DDE-300, Emec, Sera, MILTON ROY, Grundfos, ProMinent, Graco Husky, WILDEN, AquaViva, AGRAL DDE-160, AGRAL DDE-600, YAMADA NDP, DUOTEK FOOD, DEPA РМ (Р), DELLMECO DMCX, DELLMECO DM, Duotek AF Zone 2 Atex, AlphaDynamic Ruby, DUOTEK SANI, AGRAL DDE-100, AGRAL DDE-60, AGRAL DDE-030, DEPA L, DEPA DB, DEPA М, Debem FOODBOXER, Debem BOXER |
| Weight, kg | 0,7 |
Download instructions, catalog for Pneumatic Membrane Pump PHOENIX P07 PVDF ATEX
