| Producer | FLUIMAC |
| Pump capacity, cu.m/hour | 0.48 |
| Feed height, m | 80 |
| Material | POM-C |
| Input pipe diameter | 1/4" |
| Output pipe diameter | 1/4" |
| Noise level ,dB | 62 |
| Explosion protection | Yes |
| Max.flow rate, m3/h | 0.48 |
| Max. head, m | 80 |
| Max.temperature, C | 95 |
| Material of flow channel | POMc |
| Max.viscosity, cPs | 6 000 |
| Max.air pressure, bar | 8 |
| Flow rate, l/min | 8 |
| Max.diameter of solid inclusions, mm | 2,5 |
| Model | PHOENIX ATEX 07 |
| Diametr of the product line | 1/4" |
| Diameter of the pneumatic mainline | 4 mm |
| Material of ball valves | PTFE |
| Diaphragm material at air side | NBR+PTFE |
| Diaphragm material at water side | PTFE |
| Material of valve seat | POMc |
| Dry suction height, m | 3 |
| Suction capacity (NPSH), m | 9,8 |
| Serial number of the pump | PHOENIX ATEX |
| Country of Origin | Italy |
| PumpType | membrane pneumatic |
| Drive Type | pneumatic |
| Availability of spare parts | Yes |
| Warranty, months | 12 |
| Application | ammonia, varnish, ash, paints, oleum, butane, viscous liquids, saturated amine, urea, nitric acid, acetic acid, alkalis, reverse osmosis systems, alcohol, sulfur, hydrogen, peroxide, phenol, slag, ethers, ethylene, phosphoric acid, kaolin suspension, phosphates, formalin, clays, slip, carbonate |
| Analogue for | Sera, Injecta, Seko, Debem SANIBOXER, PRODOSE, DOSITEC, Milwaukee, Astralpool, MILTON ROY, AGRAL DDE-300, Graco Husky, WILDEN, AquaViva, AGRAL DDE-160, AGRAL DDE-600, Duotek AF Zone 2 Atex, DUOTEK FOOD, DEPA РМ (Р), DELLMECO DMCX, DELLMECO DM, YAMADA NDP, DUOTEK SANI, AlphaDynamic Ruby, AGRAL DDE-100, AGRAL DDE-60, AGRAL DDE-030, DEPA L, DEPA DB, DEPA М, Debem FOODBOXER, Debem BOXER, ProMinent, Grundfos, Emec, AQUA, FWT, Jesco Pump |
| Weight, kg | 0,9 |
| Producer | FLUIMAC |
| Pump capacity, cu.m/hour | 0.48 |
| Feed height, m | 80 |
| Material | POM-C |
| Input pipe diameter | 1/4" |
| Output pipe diameter | 1/4" |
| Noise level ,dB | 62 |
| Explosion protection | Yes |
| Max.flow rate, m3/h | 0.48 |
| Max. head, m | 80 |
| Max.temperature, C | 95 |
| Material of flow channel | POMc |
| Max.viscosity, cPs | 6 000 |
| Max.air pressure, bar | 8 |
| Flow rate, l/min | 8 |
| Max.diameter of solid inclusions, mm | 2,5 |
| Model | PHOENIX ATEX 07 |
| Diametr of the product line | 1/4" |
| Diameter of the pneumatic mainline | 4 mm |
| Material of ball valves | PTFE |
| Diaphragm material at air side | NBR+PTFE |
| Diaphragm material at water side | PTFE |
| Material of valve seat | POMc |
| Dry suction height, m | 3 |
| Suction capacity (NPSH), m | 9,8 |
| Serial number of the pump | PHOENIX ATEX |
| Country of Origin | Italy |
| PumpType | membrane pneumatic |
| Drive Type | pneumatic |
| Availability of spare parts | Yes |
| Warranty, months | 12 |
| Application | ammonia, varnish, ash, paints, oleum, butane, viscous liquids, saturated amine, urea, nitric acid, acetic acid, alkalis, reverse osmosis systems, alcohol, sulfur, hydrogen, peroxide, phenol, slag, ethers, ethylene, phosphoric acid, kaolin suspension, phosphates, formalin, clays, slip, carbonate |
| Analogue for | Sera, Injecta, Seko, Debem SANIBOXER, PRODOSE, DOSITEC, Milwaukee, Astralpool, MILTON ROY, AGRAL DDE-300, Graco Husky, WILDEN, AquaViva, AGRAL DDE-160, AGRAL DDE-600, Duotek AF Zone 2 Atex, DUOTEK FOOD, DEPA РМ (Р), DELLMECO DMCX, DELLMECO DM, YAMADA NDP, DUOTEK SANI, AlphaDynamic Ruby, AGRAL DDE-100, AGRAL DDE-60, AGRAL DDE-030, DEPA L, DEPA DB, DEPA М, Debem FOODBOXER, Debem BOXER, ProMinent, Grundfos, Emec, AQUA, FWT, Jesco Pump |
| Weight, kg | 0,9 |
Download instructions, catalog for Pneumatic Membrane Pump PHOENIX P07 POM ATEX
